High Speed 4 Axis Palletizing Robot Nachi LP130 210KG

Ask Lasest Price
Brand Name :	NACHI
Certification :	CE
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	999 sets/month
Delivery Time :	6-8 weeks

Add to Cart

Product Details
Company Profile

High Speed 4 Axis Palletizing Robot Nachi LP130 210KG

4-axis palletizing robot Nachi LP130 is flexible and agile and High-speed palletizing for industrial robot

Description:

Nachi LP Series Palletizing Robots are available in 130Kg, 180Kg, and 210Kg payload with high-speed palletizing, compact layout and easy operation capabilities.

Easily lift different shapes and sizes
Compact design reduces interference within a large operating range so work area layouts can be flexible and compact
Teaching operations are easy for novices to understand, interactive instructions are possible, automatic program generator
Spot and seam welding,Shipping and receiving (palletizing),Material handling

Name			LP130-01	LP180-01
Structure
Number of Axes			4
Payload		Arm	130kg	180kg
		Wrist	25kg
Positional Repeatability			±0.3mm	±0.4mm
Drive system			AC
Working Range	Arm	J1(Rotation)	±3.14rad(±180°)
		J2(Lower arm)	+0.71~-1.65rad(+41°~-95°))
		J3(Upper arm)	+0.30~-2.04rad(+17°~-117°)
	Wrist	J4(Swing)	±6.28rad(±360°)
Max. Speed	Arm	J1(Rotation)	2.27rad/s(130°/s)	2.01rad/s(115°/s)
		J2(Lower arm)	2.01rad/s(115°/s)	1.75rad/s(100°/s)
		J3(Upper arm)	2.01rad/s(115°/s)	1.83rad/s(105°/s)
	Wrist	J4(Swing)	6.98rad/s(400°/s)	6.28rad/s(360/s°)
Wirst Allowable Load	Allowable Moment Of Inertia	J4(Swing)	50kg・m2	69kg・m2
Ambient temperature			0~45℃
Mass (Weight)			1150 kg
Setting method			Floor mount

item	value
Applicable Industries	Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Restaurant, Printing Shops, Construction works , Food & Beverage Shops, Advertising Company
After Warranty Service	Video technical support, Online support
Local Service Location	Egypt, Turkey, United States, Italy, Brazil, Mexico, Russia, Spain, Australia, Morocco, Kenya, Colombia, Sri Lanka, South Africa, None
Showroom Location	Egypt, United Kingdom, Italy, Philippines, Brazil, Peru, Mexico, Spain, South Korea, Chile, UAE, Algeria, Romania, South Africa, Kazakhstan, Malaysia, Australia
Video outgoing-inspection	Provided
Machinery Test Report	Provided
Marketing Type	Ordinary Product
Warranty of core components	1 Year
Core Components	PLC, Engine, Gearbox, Gear
Condition	New
Horizonal Travel(mm)	2654 mm
Place of Origin	China
	Shanghai
Brand Name	NACHI
Weight	960kg
Power	220V
Certification	CE
Warranty	1 Year
	Online support
Robot type	LP130
Structure	Articulated
Number of axis	6
Drive system	AC servo motor
Max. payload	max130-210kg
Position repeatability	±0.02mm
Max. reach	2654mm
Installation	Floor/Inverted
Robot mass	1150kg

Our service:

1.Swift delivery
For common parts, we can deliver the goods within 3 days

2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

3.Quality Assurance

4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.

5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.

Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company.

Application:

dispensing, finishing, material handling, pick and place, assembly, palletizing, 3d printing, and remote tcp.
